650/75-32 (24.5-32) SPB260 16L TL

ASCENSO

Product sheet

Information

Code	AS2255
EAN	8904365504727
Model	SPB260
Ply/Ply Rating	16
Product type	Agriculture
Construction	Cross Ply
TT/TL	TL
Recommended rim	DH21DH21B
Pressure* (bar)*	2.10
Retreaded	NO

Load Index/ Speed Code

Load Index	164
Speed Rating	A6
Load capacity 1 (kg)	5000
Recommended load at 40km/h (kg)	4000
Speed (km/h)	30

Dimension and weight

Dimension	650753224532
Width (mm)	625.00
Diameter (mm)	1755.00
Rolling circumference (mm)	5249.00
Weight (kg)	196.58
Radio bajo carga (mm)	795.00

*Technical data are for information purposes only, may be subject to modifications by the manufacturer and are valid except in the case of typographical errors.

*The inflation pressure is always determined according to the load per tyre, the speed and the work to be performed. The following recommendations are given subject to subsequent modifications.
